FSL-5 5 Steps Ophthalmic Slit Lamp Microscope

FSL-5 5 Steps Ophthalmic Slit Lamp Microscope

Description

FSL-5


FLS-5 SLIT LAMP
FLS-5 slit lamp is a high-quality Haag-Streit type, Galilean system slit lamp. 5-step revolving drum and 14mm broad beam
ensures that eye health professionals can accurately diagnose various eye conditions.

Excellent LED light source could ensure 600,000 Lux high illumination, which lifespan is up to 50,000 hours. When Sunkingdom slit
lamp makes confocal measurement, it can provide lighting angle, more convenient for doctors to use the front mirror.

The special light source control system is designed to change the brightness of the light source through the pulse width
adjustment, the color temperature is stable, and the control light is accurate.

Brightness has no stall limited, more suitable to observe different organization position.

Specification
Microscope TypeGalilean Dystem
Magnification ChangerRevolving Drum
Eyepiece Magnification12.5X
Slit Width0mm~14mm Continuously Adjustable
Slit Length1mm~14mm Continuously Adjustable
Slit Angle0~180°Continuously Adjustable
FilterHeat Aborption, Grey, Redfree (Green), Cobalt Blue
Light SourceWarm LED
Magnification6.3X,10X,16X,25X,40X
Diopter±7D
Pupil Range52mm-85mm
Visual Field Diameter6.3X:33mm;10X:22mm;16X:14mm;25X:8.5mm;40X:5.5mm
Illumination TypeHaag-Streit Type
Illumination Tilting5°,10°,15°,20°
Slit Aperture Sizeφ0.2,φ1,φ3,φ5,φ10,φ14(mm)
